Mavic Road Center Lock Disc Front Hub

The Road Disc front hub by Mavic – CNC body, four cartridge bearings
The Mavic Road Disc Center Lock front hub comes with a CNC precision machined aluminium body that will delight wheel builders because it can easily be laced with spokes to serve as the heart of a strong and stiff disc brake wheel. With this model, Mavic harkens back to the successes of earlier hubs like the famous 501. The Road Disc front hub has two large, sealed cartridge bearings that ensure durable and smooth operation. The QRM Auto preload system ensures smooth running and optimum bearing clearance without any external intervention.
Specifications:Series:Road HubApplication:Road, Triathlon & Time Trial, Gravel, CyclocrossBrake Type:Center Lock DiscTechnical Information:Body Material:aluminiumBearings:cartridge bearings (sealed)Features:CNC precision machined bodytwo large, sealed cartridge bearings with C3 internal clearancecompatible with curved spokes (J-bend)can be converted to 9 x 100 mm quick releasedesigned and tested in France, manufactured in EuropeTechnology:QRM Auto
Qualité de Roulements Mavic Auto. The latest bearing innovation by Mavic. These cartridge bearings (bearing clearance: C3) are of course double sealed. Their bearing clearance is automatically adjusted to guarantee smooth running without any play at all times.
Models:12 x 100 mm / 24 hole:
Over Locknut Dimension:12 x 100 mm thru-axleSpoke Hole Count:24 holeFlange Distance (L/R):55.1 mm (21.4 mm/33.7 mm)Partial Bolt Circle Diameter (L/R):44 mm/44 mmManufacturer Number:H3880124
12 x 100 mm / 28 hole:
Over Locknut Dimension:12 x 100 mm thru-axleSpoke Hole Count:28 holeFlange Distance (L/R):55.1 mm (21.4 mm/33.7 mm)Partial Bolt Circle Diameter (L/R):44 mm/44 mmManufacturer Number:H3880128Contents:1 x Mavic Road Disc front hub
